A Rowing Machine Glossary

Rowing has a vocabulary, and most of it lands on you at once. A coach says “bring the split down and hold the rate at twenty,” a listing promises a “PM5-style monitor,” and a forum thread argues about drag factor as though everyone already knows what it is. None of it is complicated once the words are pinned down. This page defines them in plain English and points to the fuller guide wherever one exists. It is grouped three ways: the numbers on the monitor, the parts of the stroke, and the parts of the machine.

Monitor and pace terms

• Erg / ergometer.A rowing machine that measures the work you do, in watts, rather than merely counting strokes. The word is short for ergometer, from the Greek for “work measure.” Every erg is a rowing machine; not every rowing machine is much of an ergometer. The distinction is here.
• Split.Everyday shorthand for the 500m split — the single number rowers pace by. Lower is faster. “Hold a 2:10” means hold a pace that would cover 500 meters in two minutes and ten seconds.
• 500m split.The time it would take to cover 500 meters at your current pace, and the sport’s standard unit. It updates stroke by stroke and it is comparable between machines in a way distance and calorie figures are not. The full explanation is here.
• SPM / stroke rate.Strokes per minute — how often you are taking a stroke, counted directly. It is separate from pace: you can row the same split at a low rate with hard strokes or a high rate with soft ones. Rate and pace, untangled.
• Drag factor.Concept2’s measure of how much air the flywheel moves per stroke — effectively the true resistance the machine is applying. Because it reads the flywheel itself, it is far more consistent between machines than the 1–10 damper number. Why coaches use it.
• Watts.The raw measure of power you are producing. Everything else on a proper erg monitor — split, distance, calories — is calculated from it.
• Distance. Not a measurement of anything physically traveling, but a calculation from power over time. Two machines fed the same effort will report slightly different distances if their arithmetic differs.
• Calories. An estimate derived from watts, and a rough one. Useful for tracking your own sessions against each other, not for comparison with anyone else or with a treadmill.
• 2k.A maximal 2,000-meter test, the standard benchmark distance in rowing. Most people take somewhere between six and nine minutes and find it genuinely unpleasant. If someone gives a rowing time with no unit — “I went 7:04” — they mean a 2k.
• Rate cap. A workout setting that limits your stroke rate to a chosen ceiling, forcing you to make each stroke do more work rather than simply rowing faster. A common way to train power without letting the rate run away.
• Pace boat.The small animated boat on a Concept2 screen that represents a target pace. You watch your boat against it and try not to let it slip behind — a surprisingly effective way to hold an even effort.
• PM5.Concept2’s current performance monitor, the reference display in indoor rowing. It computes power from flywheel deceleration and every competitive result is recorded on one. How to read what it shows you.

The stroke, term by term

• The catch. The front of the stroke: shins vertical, arms straight, body tipped slightly forward, coiled and ready. The loaded position the drive starts from.
• The drive.The powered phase. Legs push first, then the body swings back, then the arms draw the handle in — roughly 60% of the power comes from the legs alone.
• The finish.The back of the stroke: legs flat, body leaning back to about eleven o’clock, handle drawn to the bottom of the ribs.
• The recovery. The return to the catch, sequenced in reverse: arms away, then body forward, then knees bend and the seat slides up. Controlled, not rushed.
• Ratio.The relationship between the time spent driving and the time spent recovering. A good recovery takes roughly twice as long as the drive; losing that ratio is what rowers mean by “rushing the slide.”
• Layback.How far you lean back at the finish. About eleven o’clock is right; lying flat loads the lower back and adds nothing.
• Rushing the slide. Hurrying the recovery so the seat shoots back to the catch, throwing off timing and pace. The most common rhythm fault. The stroke, in four positions.

The machine, part by part

• Flywheel. The wheel that spins when you pull. On an air rower it is a fan; on a magnetic rower it is a weighted disc braked by magnets; on a water rower it is paddles in a tank. It stores and releases the energy of each stroke.
• Fan cage / flywheel housing. The shroud around the flywheel. On an air rower it is where the wind noise comes from, and where the damper lever lives.
• Damper.The lever numbered 1 to 10 on the side of an air rower’s flywheel housing. It changes how much air reaches the fan — the feel of the stroke — not how hard you have to work. It is not a difficulty dial. What it actually does.
• Monorail. The single beam the seat runs along on most modern machines. Its length is what determines whether a tall rower can reach full leg extension, which makes it one of the specifications that matters most and is published least.
• Seat and rollers. The sliding seat and the wheels that carry it along the rail. Grit on the rail is the usual cause of a rough, noisy slide.
• Handle and chain / strap. What you pull. A chain is durable and slightly noisier; a nylon strap is quieter and, on some machines, the part that eventually needs replacing.
• Footplates / foot stretchers. The adjustable plates your feet strap into. Set too high and you cannot reach the catch cleanly; set too low and your heels lift on every stroke.

Machine types you will hear named

Air rower— resistance from a fan, load rising the harder you pull, and the type most ergs belong to. Magnetic rower— resistance from magnets, quiet and consistent but capped. Water rower — paddles in a tank, prized for feel and sound. Hybrid— a machine combining air and magnetic resistance. The words describe how the flywheel is braked, and that is most of what separates one machine from another.

Once the vocabulary stops being noise, the specifications on a listing start to mean something. If you want the machine most of these words were written around, that is the Concept2 — our review is here, and the full field is here.
